NEMA PET散射模体


品牌: 美国biodex
单价: 100.00元/套
起订: 1 套
供货总量: 1000 套
发货期限: 自买家付款之日起 3 天内发货
所在地: 广东 深圳市
有效期至: 长期有效
最后更新: 2024-03-28 09:33

公司基本资料信息
详细说明

NEMA PET Scatter Phantom™是根据美国国家电气制造商协会(NEMA)的建议设计的,用于在存在散射*的情况下标准化闪烁相机的计数率性能测量*

使用NEMA 2007标准(NU 2-2007)进行验收测试
确定成像系统对散射辐射的相对敏感度
测量死区时间的影响以及线源不同活动等级产生的随机事件的影响
*正电子发射断层扫描仪的性能测量,NEMA标准出版号NU2,美国国家电气制造商协会(NEMA),华盛顿特区 - 2001年

NEMA PET Scatter Phantom,NEMA PET散射模体产品规格
在散射的情况下对闪烁相机的计数率性能进行标准化*
是一个坚实的正圆高密度聚乙烯圆筒
平行于圆柱体中心轴线的可填充线源支架偏移距离为4.5厘米
气缸由四个部分组成,便于携带/存放
外径: 203厘米
长度: 70厘米
孔尺寸: 6.4 mm
偏移距离: 4.5厘米
线源插入:长度:80厘米; 内径:3.2mm; 外径:5mm

NEMA PET Scatter Phantom,NEMA PET散射模体主要应用:
NEMA标准验收测试
确定影像系统对散射辐射的相对灵敏度度
测量线源在不同活度水平下产生的死时间影响和随机事件影响

NEMA PET Scatter Phantom,NEMA PET散射模体
NEMA Scatter Phantom SET   Model ECT/NEM-SC/P

Main Features:
The NEMA Scatter Phantom Set is designed in accordance with the recommendations by the National Electrical manufacturers Association
(NEMA) to standardize the measurement of count rate performance of a scintillation camera in the presence of scatter*
 Is a solid right circular high density polyethylene cylinder
Has a fillable line source holder parallel to the center axis of the cylinder and offset a distance
O.    D. 4.5 cm
The cylinder is made of four sections for ease of carrying/storage


Main Applications:
Acceptance testing with NEMA standard
Determine the imaging systems relative sensitivity to scatter radiation
Measure the effects of dead-time and the effects of random events generated at different levels of activity of the line source


Specifications:
Outside diameter: 203 cm Length: 70 cm
Hole size: 6.4 mm Offset distance: 4.5 cm Line source insert: Length: 80 cm
I.D.: 3.2 mm
C.D.: 5 mm

NEMA PET Scatter Phantom,NEMA PET散射模体

NEMA PET Scatter Phantom,NEMA PET散射模体
NEMA PET Scatter Phantom,NEMA PET散射模体
